Double Acting Double Block&bleed Ball Valve
PMV Double Acting Double Block&bleed Ball Valve is equipped with Pneumetic or electric actuator to achieve double acting function and emergency shut-off. With the function of emergency shut-off, PMV DBB ball valve also can operate with the function of double block and bleed. Even one closure element is suddenly ineffective, the other one can still operate with the function of block and bleed. PMV Double acting DBB ball valve is sold to the world and applying for Petroleum and natural gas pipe, which bring the perfect flow solution to our clients.
VALVE DESIGN
API 6D, API 6A, ASME B16.34, ISO 14313, ISO 10423, ISO 17292
TEMPERATURE RANGE
-58 to 392°F (-50 to 200°C)
SIZE
NPS 1-12 (DN 25-300)
PRESSURE RATING
ASME 150 - ASME 2500
FACE-TO-FACE
As per API 6D standard
END CONNECTIONS
RF, RTJ as per B16.5 &B16.47
BW, Butt Welded as per B16.25
SW, Socket Welded as per B16.11
MATERIALS
Low Temperature and Low Alloy Carbon Steel
Stainless steel, Duplex and Super Duplex
Nickel alloys, Titanium
BODY DESIGN
Forged and casting bolted two-piece and three-piece
SEAT DESIGN
Soft or metal seated with Hard facing on ball and seats
Double piston seats
Combination seats
FEATURES
Double block and bleed design (DBB)
Secondary seals in pure Graphite
Anti-Static Device
Anti Blow out stem
Emergency sealant injection on seats and stem available
Low fugitive emission stem packing available
O-ring /Lip seals and Graphite configuration
CRA overlay on all dynamic sealing areas or on all wetted parts available
Extended bonnet for low & high temperature available
OPERATOR
Manual: wrench or Gear with padlocking
Actuated: Pneumatic/Electric
TESTING & CERTIFICATIONS
Compliance with API 6D & ISO 5208 & API 598 inspection and testing
Fire safe and fire tested as per API 607
SIL 3 Certification as per IEC61508
Fugitive Emission as per ISO15848
PED 2014/68/UE
MAIN APPLICATIONS
•Offshore oil & gas production
•Gas & oil terminals
•Chemical & Petrochemical
•Refining
•Fiscal Metering Skid Manufacturing
•LNG gas carrier
•Process/ Power industr y contractors
ADVANTAGES
•Space and weight saving
•Cost saving (product & installation)
•Minimized leak paths
•Increased line structural integrity
•ESDV+MOV or ESDV+XV configurations
•Increasesd reliability of the system
FAQ
Q: The mechanical property of TCC,CCC, STL
A: TCC: The hardness is extremely high. The surface hardness of Ball valve with TCC can be up to 1050HV-1450HV( about 70 HRC).It has excellent wear resistance, but the thicker the coating, the lower the adhesion. CCC: Under extremely high temperature(900℃), Ball valve with CCC can still keep low friction coefficient and excellent wear resistance. STL:The hardness of cobalt-based alloy after spray welding is generally 38 - 52 HRC, while that of nickel-based alloy is 50 - 60 HRC. It possesses both corrosion resistance and wear resistance.
Q: How to achieve Doulbe acting function?
A: For achievng double acting function, we need to change our operation way of ball valve to Actuator acting. Equipped with pneumatic or electric actuator, ball valve can have the ability to emegency open the closure element and shut down it. By the way, if you want to purchase the actuator by yourself, we will offer our price with bare stem and attache the ISO pad information and torque value for you to select suitable actuator by yourself.
